Product details
Voltage: Electronic ballast: AC100V / 120V / 200V / 220V / 230V / 240V, 50 / 60Hz
Inductive ballast: AC 220-240V, 50 / 60Hz
Rated power: 1500 watts
Light bulb specifications: OSRAM HTI 1200W / D7 / 60 double-ended bubble, color temperature: 6000K
Color: CMY, 0-100% linear color mixing system
6 color film + blank, do two-way variable speed rainbow effect, CTO color temperature is correct
Pattern: two rotating pattern discs
10 replaceable pattern + blank, with indexing function and bidirectional rotation effect
Dynamic wheel: two-way variable speed rotation, combined with other patterns can produce watermark, flame and other effects
Focus: Linear focus
Zoom: 10 ° -60 ° (6: 1 optical zoom system)
Dimming: 0-100% linear dimming
Light strobe: independent two-piece strobe (1-12 times per second high-speed strobe effect)
Aperture: 5-100% linear adjustment
Light body scanning: running smooth, automatic return to correct function, adjustable speed, with 16Bit precision adjustment)
Scanning range: horizontal 540 °, vertical 270 °
Cooling system: forced convection cooling, fan speed adjustable
Control: DMX 512, three-core and five-core interface
Channel: Standard mode: 22; Extended mode: 28
Display: LCD liquid crystal display, brightness and contrast adjustable, Chinese and English intelligent user interface,
Can display the lamp bulb use time
Energy saving mode: When the shutter or dimming function is closed, the lamp power consumption automatically reduced to 50%
Protection class: IP20, built-in overheating and triggering high voltage protection
Net weight: electronic ballast: 45.5Kg; inductance ballast: 55.5Kg
Gross weight: air box, electronic ballast: 93.5Kg; inductance ballast: 103.5Kg
Light body size: length 594 × width 535 × height 843 (mm)
Packing size: Air box: length 690 × width 620 × height 930 (mm)
